Contact wire ETP 350MCM
Contact wire ETP 350MCM
Contact wire for catenary
Read more- Nexans ref. : 22000193
- Country ref. : Canada
Description
Description
Standards
-
NationalASTM B 47
Characteristics
Characteristics
Dimensional characteristics
Dimensional characteristics
Approximate weight
1.582 kg/m
Conductor cross-section
178 mm²
Electrical characteristics
Electrical characteristics
Max. DC resistance of the conductor at 20°C
0.098 Ohm/km
Minimum conductivity at 20°C
99 % IACS
Mechanical characteristics
Mechanical characteristics
Minimum Elongation
4.5 %
Minimum Tensile Strength
310 MPa
Minimum breaking load
55.18 kN
Resources
Resources
Selling & delivery Information
Contact wire is produced on reel (steel or wooden reel). Reel dimension can be customized to meet customer requirement.
